제품 상세 정보:
|
| 유형: | 핸드 헬드 | 화면 매개변수: | 1.8'', TFT LCD(320×240) |
|---|---|---|---|
| 기본 및 보조 배터리: | 7.2~8.4V,3000mAh | 메모리/스토리지: | 2GB RAM+16GB ROM,128G 마이크로 SD |
| 작동 빈도: | 520-650, 1200-1500MHz | 캐리어 대역폭: | 1.25/2.5/5/10/20MHz 설정 |
| 강조하다: | BEAMmesh handheld MANET broadband device,MESH wireless broadband handheld unit,MANET broadband MESH communication tool |
||
| System Parameters | |
| Application processor | Octa-core A53 processor with maximum operating frequency of 1.8GHz |
| Operating system | Android 6.0 |
| Screen parameter | 1.8'', TFT LCD(320 X 240) |
| Memory/storage | 2GB RAM+16GB ROM, 128G Micro SD |
| Voice services | Supports VoIP (PTT) and multi-party conferences |
| Data service | Support file transfer, short message, GIS, iot data transmission, etc |
| Video service | Video pull-up, video conferencing, and more are supported |
| Audio, video and data interfaces | 20PIN LEMO IP/USB, 5PIN aviation head words, WiFi IP |
| Main and standby batteries | 7.2~8.4V,6800mAh |
| Endurance time | ≥6h (Transmit: Receive: idle = 1:1:1) |
| Locate the navigation | Built-in GPS/BD |
| Size | 15.5x6.6x3.2cm (Contains lithium battery, does not include antenna and back clip) |
| Weight | 430g (Contains lithium battery, does not include antenna and back clip) |
| Environmental | |
| Protection Level | IEC60529-IP67(1.5m,0.5h) |
| Shock and vibration | MIL-STD-810G |
| Operation Temperature | -40ºC~+80ºC |
| Storage temperature | -55ºC~+100ºC |
| Humidity requirement | 10%~90%(No condensation) |
| Wireless communication | |
| Communication format | Mobile Ad-hoc NETworking Ad hoc network |
| Working frequency (70M~6GHz, customized) |
350-450/450-550/570-700/800-950MHz, 1000-1200/1300-1500/1600-1800/1800-2000,1200-1700*MHz, 2.0-2.2/2.2-2.5/2.5-2.7/2.7-2.9,1.6-2.3/1.9-2.7*GHz, 4.4-5.0/5.25-5.85, 4.2-5.2/5.5-6.0*GHz |
| Transmission system | TDD-COFDM |
| Receive sensitivity | ≤-103dBm@5MHz |
| Transmit power | 1W |
| Carrier bandwidth | 1.25/2.5/5.0/10.0MHz Optional |
| Transmission capability | 56Mbps@10MHz |
| Modulation Mode | BPSK/QPSK/16QAM/64QAM/256QAM(Adaptive) |
| Network scale | Same-frequency networking supports more than 256 nodes |
| Anti-jamming Mode | Inter-frequency intelligent channel selection, full-band dynamic adaptive frequency hopping |
| Encryption | DES56/AES128/AES256 Optional |
| Interface | |
| Antenna Interface | SMAx2 |
| IP Interface | Waterproof navigation plug (reusable with USB interface) |
| USB Interface | Waterproof navigational plug (reusable with IP interface) |
| Headset interface | Contact Wired Headset (PTT) |
| Basic peripheral | Microphone (dual MIC), speaker |
| Front key | Menu button, Home button, confirm button, back button, 4 way button, number button |
| Side key | PTT button, Volume adjustment button, Power button (top), SOS button (top) |
| WiFi AP | 2.4GHz/5.8GHz,802.11b/g/h |
